CORE (Round)
by ALW
Our CORE cylinders provide aesthetic design forms without compromising on performance. The CORE Round model (formerly CORE LX) features lumen packages up to 6,000 lumens and precise optics ranging from 15° – 80° along with various lens accessories to add versatility to your applications. CORE round cylinders are available with direct and direct/indirect output combinations from 3.5”, 4.5” and 6” apertures by 8.1″ – 15.4″ long shells. These models are available with pendant, yoke, sconce, and surface mounting to fit a variety of spaces.
Specsheets
ALW_Catenary_Design_Guide_200405.pdf
ALW-Buy-American-Act.pdf
ALW-DMX_RDM-Luminaire-Information-Guide-Rev-1-2_13_23.pdf
CORE-3-Round-Direct-PMSY-Spec-Sheet-060622.pdf
CORE-3-Round-Direct-Indirect-PS-Spec-Sheet-060622-1.pdf
CORE-4-Round-Direct-Indirect-PS-Spec-Sheet-060622-1.pdf
CORE-4-Round-Direct-PMSY-Spec-Sheet-060622.pdf
CORE-6-Round-Direct-Indirect-PS-Spec-Sheet-060622-1.pdf
CORE-6-Round-Direct-PMSY-Spec-Sheet-060622.pdf
CORE-4-Round-Direct-PMSY-Spec-Sheet-230213.pdf
CORE-4-Round-Direct-Indirect-PS-Spec-Sheet-230209.pdf
CORE-3-Round-Direct-PMSY-Spec-Sheet-230209.pdf
CORE-3-Round-Direct-Indirect-PS-Spec-Sheet-230209.pdf
CORE-6-Round-Direct-PMSY-Spec-Sheet-230213-1.pdf
CORE-6-Round-Direct-Indirect-PS-Spec-Sheet-230213.pdf
Photometry
CCT
2700K , 3000K , 3500K , 4000K
CRI
90
Color / Finish
Black , Brass , Brushed Aluminum , Copper , Custom , Dark Bronze , Red , Satin Black , Satin White , Silver Gray , Stainless Steel , Tan , Teal
Dimming Protocol
0-10 V , DALI , DMX , Lutron EcoSystem , Standard Phase
Dimming Range
1% , Non-Dimmable , Step-Dimming
Dynamic LED Color
BIOS SkyBlue , RGB , RGBW , Tunable White
Efficacy
77, 82, 90, 93, 121, 124, 128, 132, 139, 150
Lamp Source
LED
Listings
ETL , UL
Lumens
500, 1000, 1500, 2000, 2500, 3000
Materials
Aluminum , Copper , Nylon , Steel
Mounting
Pendant , Suspended , Wall
Ratings & Compliance
Buy American Act (BAA) , Wet
Warranty
11 yr
